Four-Transistor Bipolar Series-Parallel Module Structure for Cascaded Bridge and Modular Multilevel Circuits

Abstract

—With their great scalability and flexibility, cascadedbridge and modular multilevel converters have enabled a variety of energy applications, such as offshore wind power, high-voltage dc power transmission, power-quality management, and cuttingedge medical instrumentation. The incorporation of parallel connectivity between modules equips systems with advantages such as sensorless balancing, switched-capacitor energy exchange, and reduced impedance. However, existing topologies require many individual switches—eight transistors per module. Efforts to use fewer switches, instead, have previously compromised their functionality. We propose a new module topology, named the direction-selective parallel (DiSeP) structure, which requires only four transistors per module—the same as an H bridge—but can achieve bidirectional equilibration, bipolar module output, and inter-module switched-capacitor features.
