Star Grazing with Alumina Grass: Antireflection coatings in the visible and near-infrared on IPX-Clear Microlenses assisted by Grass-like Alumina

Abstract

Two-photon polymerization (2PP) enables the fabrication of high-precision micro-optics with complex freeform geometries, opening up a new parameter space for custom astronomical optics. Among the available resins, the newly developed IPX Clear is particularly well suited for visible applications, offering very high transmission rates across the visible and near-infrared spectrum, low surface roughness, and excellent shape fidelity. However, Fresnel reflections at the air–polymer interface introduce significant optical losses, which are detrimental in lowsignal applications such as astronomy, where ever bigger telescopes are being built to collect more photons. Previous studies have found that grass-like alumina coatings on traditional glass and fused silica lenses improve average transmission from 91.9% up to 99% in the 400–900 nm spectral range. In our project, we explore the feasibility of Atomic Layer Deposition (ALD) for applying such a coating to IPX-Clear based micro-optics. In the 400-1700 nm range. Grass-like alumina based anti-reflective (AR) coatings can be designed to approximate the ideal refractive index for perfect destructive interference. This can be done by generating a gradual refractive index transition from air to the bulk IPX Clear substrate, suppressing surface reflections. While such grass-like coating has been demonstrated on bulk optics, and conformal ALD coatings have been applied to micro-optics built using 2PP. We demonstrate here— for the first time— the application of alumina grass coating to microlenses built using 2PP with the new IPX-Clear resin. In this study we have discussed the challenges and process steps of such applications. We observed Alumina grass coated micro lenses approximately lose 0.3% of photons due to reflection in the 400-850 nm range. In future work, we plan to test the performance of these microlenses in the entire 400-1700 nm range and explore methods to make coating more resilient, such as by applying an overcoat of SiO 2 .
